KLD- LB Series Lead-acid Batteries

KLD-LB series Lead-acid Batteries uses Absorbent Glass Mat (AGM) technology, thus saving the requirements for adding electrolyte or distilled water during use.

It mainly uses the positive pole to produce oxygen which can be absorbed in the negative pole to achieve oxygen circulation and prevent water loss. When charging and discharging, there will be no acid mist like the old lead-acid battery, which will corrode the equipment and pollute the environment. Compared with the original lead-acid battery, it has many advantages and is very popular with users, especially those who need to install the battery supporting equipment together (or a workshop).
The KLD-LB series covers the following batteries: KLD-LB6&KLD-CB12 series Lead-acid Batteries with design life of 12 years, KLD-LB12-F series front-end Lead-acid Batteries with design life of 15 years, and KLD-LB2-S series fixed Lead-acid Batteries with design life of 16 years.

Advantages of Lead-acid Batteries

  • Not leaking acid

    Sealed structure, does not leak acid, can be used at any position (except for battery terminal upside down)

  • Maintenance-free

    Maintenance-free, no need to add water

  • Special formula, corrosion resistance

    Special lead-calcium alloy formula, strong corrosion resistance, long life and good economy

  • Long float life

    Extremely low floating charge current and long battery life

  • Safe and reliable

    Safety valve opens in one direction, safe and reliable

  • Less impurities

    High-purity electrolyte with less impurities

  • Extremely low gas emissions

    Recombination inside the gas, the recombination efficiency is up to 99%, and the gas emission is extremely low

  • ABS material pool shell

    ABS material pool shell, optional PP material, UL94-HB grade (UL94-V0 flame retardant grade can be made according to demand)

  • AGM technology

    High-Compression Glass Fiber Wool Aspiration (AGM) Technology

  • Low self-discharge rate

    Low self-discharge rate, less than 3% per month

Technical Characteristics

  • KLD-LB series batteries are designed to keep the electrolyte required for the battery in the plates and separators, and there is no free electrolyte in the battery. At the same time, the specially designed negative plate enhances the ability to absorb oxygen, and the gas recombination rate is high, ensuring the battery's tightness.

    KLD-LB series batteries are designed to keep the electrolyte required for the battery in the plates and separators, and there is no free electrolyte in the battery. At the same time, the specially designed negative plate enhances the ability to absorb oxygen, and the gas recombination rate is high, ensuring the battery's tightness.

  • Battery cathode and anode plate

    A grid made of a special high tin-lead-calcium alloy filled with active materials

    Battery cathode and anode plate

    A grid made of a special high tin-lead-calcium alloy filled with active materials

  • Bulkhead

    Made of glass fiber cotton with excellent acid resistance, which can effectively prevent short circuit between positive and negative poles, and can well absorb and maintain the electrolyte, and compact the surface of the electrode plate to prevent the active material from falling off.

    Bulkhead

    Made of glass fiber cotton with excellent acid resistance, which can effectively prevent short circuit between positive and negative poles, and can well absorb and maintain the electrolyte, and compact the surface of the electrode plate to prevent the active material from falling off.

  • Vent

    Made of excellent acid and aging resistant synthetic rubber, and it has a one-way valve. When the internal pressure of the battery is too high, the gas is released to restore the internal pressure to normal, which can prevent the air from being drawn into the battery.

    Vent

    Made of excellent acid and aging resistant synthetic rubber, and it has a one-way valve. When the internal pressure of the battery is too high, the gas is released to restore the internal pressure to normal, which can prevent the air from being drawn into the battery.

  • Battery case, cover

    Made of synthetic resin ABS with sufficient strength

    Battery case, cover

    Made of synthetic resin ABS with sufficient strength

  • Terminal

    The terminal structure is double-sealed with sealing resin after the lead sleeve embedded in the battery cover and the terminal are welded. The positive electrode is red and the negative electrode is black. In order to improve the high-rate discharge performance and reliability, increase the terminal load, and easy to install the connection board and lead-out terminals

    Terminal

    The terminal structure is double-sealed with sealing resin after the lead sleeve embedded in the battery cover and the terminal are welded. The positive electrode is red and the negative electrode is black. In order to improve the high-rate discharge performance and reliability, increase the terminal load, and easy to install the connection board and lead-out terminals

Type selection of specification of KLD- LB series Lead-acid Batteries

（1）Specification of KLD-LB6& KLD-LB12 series Lead-acid Batteries（Design life of 12 years @20℃）

Capacity (Ah) Maximum size (mm)
Battery model Rated voltage (V) 20 hour rate1.75V / cell Length (L) Width (W) Height (H) Total height (Th) Terminal post
KLD-LB6-200 6 200 306 169 220 226 M8
KLD-LB6-220 6 220 306 174 220 226 M8
KLD-LB12-18 12 18 181 77 167 167 M5
KLD-LB12-22 12 22 181 77 167 167 M5
KLD-LB12-24 12 24 166 126 174 174 M5
KLD-LB12-26 12 26 165 176 125 125 M6
KLD-LB12-35 12 35 196 131 155 167 M6
KLD-LB12-40 12 40 198 166 174 174 M6
KLD-LB12-45 12 45 198 166 174 174 M6

KLD-LB12-55 12 55 229 138 208 212 M6
KLD-LB12-65 12 65 351 167 176 176 M6
KLD-LB12-80 12 80 260 169 211 215 M6
KLD-LB12-100A 12 100 328 172 214 220 M8
KLD-LB12-100B 12 100 307 169 211 215 M8
KLD-LB12-120 12 120 331 175 214 218 M8
KLD-LB12-150 12 150 341 173 281 287 M8
KLD-LB12-160 12 160 484 171 241 241 M8
KLD-LB12-180 12 180 530 209 214 218 M8

KLD-LB12-200 12 200 530 209 214 218 M8
KLD-LB12-220 12 220 522 242 218 222 M8
KLD-LB12-240 12 240 520 269 204 208 M8
KLD-LB12-260 12 260 521 269 220 224 M8
KLD-LB12-280 12 280 521 269 220 224 M8

（2）Specification of KLD-LB12-F series front-end Lead-acid Batteries（Design life of 15 years @20℃）

Capacity (Ah) Maximum size (mm)
Battery model Rated voltage (V) 10 hour rate1.80V / cell Length (L) Width (W) Height (H) Total height (Th) Terminal post
KLD-LB12-55-F 12 55 278 106 223 223 M6
KLD-LB12-80-F 12 80 562 114 188 188 M6
KLD-LB12-95-F 12 95 395 105 255 266 M6
KLD-LB12-105-F 12 105 508 111 227 227 M8
KLD-LB12-115-F 12 115 394 110 286 286 M8
KLD-LB12-130-F 12 130 550 110 240 240 M8
KLD-LB12-165-F 12 165 560 110 287 387 M8
KLD-LB12-185-F 12 185 560 125 317 317 M8

（3）Specification of KLD-LB2-S series fixed Lead-acid Batteries（Design life of 16 years @20℃）

Capacity (Ah) Maximum size (mm)
Battery model Rated voltage (V) 10 hour rate1.80V / cell Length (L) Width (W) Height (H) Total height (Th) Terminal post
KLD-LB2-200-S 2 200 172 110 330 365 M8
KLD-LB2-300-S 2 300 172 150 330 365 M8
KLD-LB2-400-S 2 400 211 175 330 367 M8
KLD-LB2-500-S 2 500 241 172 330 365 M8
KLD-LB2-600-S 2 600 241 172 330 365 M8
KLD-LB2-800-S 2 800 411 175 330 365 M8
KLD-LB2-1000-S 2 1000 474 175 328 366 M8
KLD-LB2-1200-S 2 1200 474 175 328 366 M8
KLD-LB2-1600-S 2 1600 401 347 342 378 M8
KLD-LB2-2000-S 2 2000 490 349 342 382 M8
KLD-LB2-3000-S 2 3000 711 353 342 382 F10

Description of specification and model of KLD-LB series Lead-acid Batteries

Model problem, welcome to inquire!

Telephone：021-6288-6915
